How To Fold A Rollator Walker For Travel and Storage (Easy Steps)

Folding your rollator walker takes less than 60 seconds once you know the right steps. Whether you’re loading it into a car trunk, storing it at home, or getting through TSA security, proper folding technique makes your rollator easier to manage and helps it last longer.

This guide covers both main rollator types with clear, step-by-step instructions and safety tips built into every step.

Important: These instructions cover most common rollator models. Always check your owner’s manual for model-specific details and safety warnings.

Which Type of Rollator Do You Have?

There are two main types of rollator walkers – side-folding and traditional.

Check which type you own before starting. This takes 10 seconds:

Side-Folding Rollator

• Strap or handle on the seat
• Folds by pulling up from the middle
• Frame becomes NARROW (sides come together)
• Usually stands upright when folded
• Common brands: Drive Medical, Medline, Hugo

Traditional Rollator

• Crossbar, strap, or release mechanism under/on seat
• Frame COMPRESSES or FLATTENS when folded
• May or may not stand when folded (depends on model)
• Common brands: Invacare, some Drive models, many European brands

Quick test:

• Side-folding: Flip up your seat. See a strap in the CENTER pulling both sides together? That’s side-folding.
• Traditional: Lift the seat. See a crossbar, strap running lengthwise, or a release button? That’s traditional.

Still not sure? Try a gentle fold test at home. If the sides come TOGETHER making it narrow, it’s side-folding. If the frame COMPRESSES front-to-back or flattens, it’s traditional.

Note: Some rollators market themselves as “longitudinal folding” or “lengthwise folding” but actually work like side-folding models (sides come together). What matters is HOW it folds, not what the marketing says.

Safety First: Before You Fold Any Rollator

Follow these four safety rules every time:

1. Flat surface
Place your rollator on level ground, never on a slope.

• Check: The rollator shouldn’t roll even with brakes unlocked

2. Lock brakes
Push both brake handles down until they click.

• Check: Try pushing gently. It shouldn’t budge at all.

3. Clear everything
Remove all items from basket, seat, and pouches.

• Check: Nothing should hang from the rollator

4. Stable stance
Stand close with feet shoulder-width apart.

• Check: You should feel balanced, rollators can weigh 10-30 lbs depending on model.

Step 3: Pull the strap upward
Grab with both hands and pull straight up in one smooth motion.

How to Fold a Side-Folding Rollator

Side-folding rollators work on the same principle but have two main designs. The difference is in how the rear wheel supports fold: some move up with the frame in one motion, others must be lifted by hand.

6-7 Steps (Depending on Your Model)

Step 1: Lock the brakes
Push both brake handles down until you hear or feel a click so the rollator cannot roll while you fold it.

Step 2: Find the folding strap or handle
Flip the seat up or look under/at the center of the seat. Find the strap, handle, or pull-tab in the middle that is meant for folding.

Step 3: Pull the strap straight upward
Grab the strap or handle with both hands and pull straight up in line with the frame in one smooth, firm motion.

• Common mistake: Jerking or pulling at an angle. Pull straight up.
• Safety: Keep fingers away from hinges and folding joints on both sides while the frame moves inward.

Step 4: Check what happened at the rear supports
As you pulled, the frame narrowed from side to side. Now look at the rear wheel supports:

Newer “one-pull” models:

• The rear supports swung up alongside the frame as you pulled
• Skip to Step 6

Older/compact models (like the video example below):

• The frame is narrow but rear supports still stick out backward in a V-shape
• Continue to Step 5

Step 5: Manual rear support folding (if needed)
If the rear supports did not come up with the frame:

• Hold the narrowed frame steady with one hand
• Lift the left rear support bar up until it’s parallel with the frame
• Lift the right rear support bar up the same way
• Both supports should now be up alongside the frame, creating a compact rectangular bundle

Step 6: Secure the folded position

• Newer models: The frame often clicks into a locked position automatically when fully closed
• Older models: Use the Velcro strap or clip on the side to wrap around the folded frame and hold everything together
• Check: Shake gently. Nothing should swing out or unfold.

Step 7: Make sure it stands safely
Most side-folding rollators stand upright when properly folded. If yours is unstable, lean it safely against a wall or lay it down in your car trunk.

How to tell which type you have: Do one test fold at home. If the rear supports come up as you pull the strap, you have a newer “one-pull” model. If they stay down and must be lifted by hand, you have a “two-step” model like the one shown in the video.

Video Demonstration

This video shows a two-step model where rear supports are lifted manually (starting at 5:20):

If you have a newer one-pull model, your rollator will fold completely in Steps 1-4 without the manual lifting shown in the video.

Unfolding Your Side-Folding Rollator

1. Release any Velcro straps or clips
2. If you manually lifted rear supports, lower them back down to walking position
3. Hold both handlebars and push them apart
4. Push down on the seat until it clicks flat and locks
5. Test the seat by pressing down hard – you should hear/feel the click
6. Unlock the brakes

Common mistake: Forgetting to fully lock the seat. Always press until you hear the click.

How to Fold a Traditional Rollator

Traditional rollators fold by flattening or compressing the frame. Older models use a crossbar mechanism, while newer models use a strap, handle, or release button. The basic principle is the same but the details vary.

6-7 Steps (Works for Most Traditional Models)

Step 1: Lock the brakes
Push both brake handles down until you hear or feel a click so the rollator cannot move while you fold it.

Step 2: Check your basket

• Older models: Remove the basket completely – it blocks the folding mechanism
• Newer models with integrated bags: The basket/bag folds with the frame – leave it attached
• Not sure? Check your owner’s manual – some bags are designed to stay on during folding

Step 3: Lift the seat
Flip the seat up to expose the folding mechanism underneath.

Step 4: Find your folding mechanism
Look for one of these:

Crossbar (older models):

• A horizontal metal bar running under the seat connecting both sides

Strap or handle (newer models):

• A pull strap at the center under the seat
• A release strap or handle on top of the seat
• A lever or button near the frame

Step 5: Pull to fold

• Crossbar models: Grab the crossbar with both hands and pull straight up. The frame will flatten.
• Strap/handle models: Pull the strap upward firmly or press the release button. The frame will compress.

Safety: Watch for pinch points near the joints on both sides as the frame collapses.

Step 6: Ensure complete folding
Keep pulling until the wheels are very close together and the frame is clearly compressed.

Common mistake: Stopping too early. The frame should feel tight and compact.

Step 7: Check the lock

• Auto-lock models (newer): Listen for a click. The frame locks automatically when fully folded.
• Manual-lock models: Look for a clip or latch on the side of the frame and engage it.
• No-lock models (older): Use a bungee cord (18-24″ length) or Velcro strap to hold the folded frame together.

Check: Shake gently. The rollator shouldn’t start to unfold.

Step 8: Storage position

• Some models: Stand upright on their own when properly folded
• Other models: Need to lean against a wall or lay flat in your car trunk

How to tell which type you have: Lift the seat and look underneath. See a metal crossbar? That’s an older model. See a strap, handle, or release mechanism? That’s a newer model. Still not sure? Check your owner’s manual for your specific folding instructions.

Video Demonstration

This video shows a traditional crossbar model:

If you have a newer model with a strap or release button, your folding mechanism will look different but the basic principle (frame compresses and locks) is the same.

Unfolding Your Traditional Rollator

The unfolding process depends on your lock type:

Newer models with release button or strap:

1. Press the release button or lift the release strap
2. The frame will start to open slightly on its own (some models have a spring assist)
3. Push the sides apart gently with both hands
4. Push down on the center of the frame or seat until fully open
5. Make sure the seat locks flat – press down hard and listen for a click
6. Check that handles are at the correct height and locked
7. Test the brakes – they should engage and release smoothly
8. Unlock brakes to walk

Older crossbar models without release mechanism:

1. Remove any bungee cords or straps
2. Hold the frame on both sides near the joints
3. Pull the sides apart with steady, even pressure (don’t jerk)
4. Push down on the crossbar or seat until frame is fully open
5. Lower the seat and ensure it locks horizontal
6. Reattach basket if you removed it
7. Check handle height and brake function
8. Unlock brakes to walk

Common mistake: Not pressing the release button fully before trying to open (newer models), or trying to force the frame open without releasing the lock mechanism.

Final safety checks before walking:

• Seat is completely flat and locked (not at an angle)
• Handles are at correct height and locked in place
• Brakes engage when you pull them and release when you push them down
• Frame feels solid with no wobbling or loose parts
• If you removed the basket, make sure it’s securely reattached

When You’ll Need to Fold Your Rollator

Loading Into a Car Trunk

Compact cars (Honda Civic, Toyota Corolla):

• Side-folding: Fits easily (10″ wide × 25″ tall when folded)
• Traditional: Usually fits, may need rear seats down

SUVs and minivans: Both types fit with room to spare.

Pro tip: Always fold your rollator on the ground BEFORE lifting it.
Rollators can weigh anywhere from 10 to 30 pounds depending on the model, so trying to fold while holding one is awkward and risks finger pinches. Fold it first, then lift the compact version into your trunk.

Air Travel

TSA requires rollators folded for X-ray screening. You can:

• Use your rollator up to the gate
• Gate-check it like a wheelchair (no fee)
• Get it back at the gate when you land

Note: No rollator fits overhead bins, even when folded. Always gate-check.

Pro tip: Arrive 30 minutes earlier than usual. Security takes extra time, especially on your first flight.

For complete TSA rules, gate-check procedures, and airport navigation tips, read our full guide: Can You Take a Walker on a Plane?

Home Storage

Closet storage: Folded side-folding rollators need about 10″ × 25″ of floor space. Fits in most coat closets.

Against walls: Some traditional rollators stand on their own when
folded, while others need to lean against a wall for support.

Hallways: ADA requires 36″ clear width. A folded rollator uses only 10-12″, staying out of the walking path.

Extra Tips for Transport and Storage

First time folding? Try it once at home before traveling. This way
you’ll know your specific model’s mechanism and won’t be surprised at the airport or when loading the car.

No built-in lock? A $5 bungee cord (18-24″ length) or Velcro strap
works perfectly to hold older traditional rollators together.

Basket concerns? If you’re not sure whether to remove your basket,
check your owner’s manual. Most newer models have baskets that fold with the frame, while older models require basket removal.

Before walking again, always check:

• Seat is fully open and locked horizontal (press down hard, listen for click)
• Rear wheel supports are in normal walking position (if you manually folded them)
• Handles are at correct height and locked in place
• Brakes engage when pulled and release when pushed
• Frame feels solid with no wobbling

Common Folding Problems and Fixes

Rollator Won’t Fold

Check these:

1. Brakes not fully locked (unlock and re-lock firmly)
2. Debris in hinges (clean them out)
3. Basket still attached – older traditional models require basket removal
   (newer models usually fold with basket attached)
4. Frame misaligned (open fully and try again)
5. Release button or lock not disengaged (newer models with auto-lock)

Solution: Start over. Unfold completely, make sure you’re on flat
ground, then follow the steps again.

Rollator Won’t Fold

Check these:

1. Brakes not fully locked (unlock and re-lock firmly)
2. Debris in hinges (clean them out)
3. Basket still attached on traditional models (remove it)
4. Frame misaligned (open fully and try again)

Solution: Start over. Unfold completely, make sure you’re on flat ground, then follow the steps again.

Rollator Unfolds While Carrying

Immediate action: Put it down before it pinches fingers.

Prevention:

• Side-folding: Always engage the security clip
• Traditional: Always use a bungee cord for transport

Can’t Unfold the Rollator

Most common cause: Release button not fully pressed.

Fix: Look for the release button (usually on the side). Press it completely while pulling sides apart.

Still stuck? Don’t force it. Check your owner’s manual for your model’s specific release location.

Helpful Accessories

Bungee cords: Useful for older rollators without
built-in locks. Get 18-24″ length.

Rollator travel bag: Protect your folded rollator from dirt and scratches in car trunks.

The Bottom Line

Folding a rollator walker takes less than 60 seconds with practice.

Side-folding rollators fold by pulling the seat strap upward. Newer
models fold completely in one pull, while older models require manually lifting the rear supports. Most stand on their own when folded. Best for frequent car travel and small storage spaces.

Traditional rollators fold by pulling the crossbar, strap, or release
mechanism. Newer models have auto-locks, while older models may need a bungee cord to stay folded. Some stand upright when folded, others need wall support.

Both types make travel, storage, and daily life easier. Practice folding
and unfolding three times today. By tomorrow, it’ll feel natural.

Planning a trip with someone who uses a rollator? Check out our
complete guide: 12 Tips for Traveling With Elderly Parents
